• 46 Inch ADA Round Contour Table 3-Seat Diamond

46 Inch ADA Round Contour Table 3-Seat Diamond, model 230H-RDVC46, is a 46-inch Round Contour Table with 3 individual contour seats and a diamond thermoplastic seating/top pattern. The current UltraSite family is portable and/or surface mount.

  • Table top: 46 in diameter
  • Table height: 30 in
  • Seat count: 3
  • Seat width: 18 in
  • Seat depth: 23-3/4 in
  • Seat height: 18 in
  • Overall footprint: Approximately 92 in round x 37 in high
  • Top / seat steel: 3/4 in #9 expanded steel
  • Coating: Oven-fused thermoplastic
  • Frame: 2-3/8" O.D. x 12-gauge pre-galvanized structural steel tubing
  • Cross braces: 1-5/16" O.D. x 15-gauge pre-galvanized structural steel tubing
  • Construction: Electrically MIG welded components with bolt-together walk-through frame geometry
  • Frame finish: Electrostatic powder coat, oven cured
  • Hardware: Stainless steel and zinc-coated fasteners
  • Umbrella hole: 1-9/16 in diameter
  • Mount: Portable and/or surface mount

The current manufacturer resource identifies this as the 3-seat accessible/ADA branch. The reduced seat count provides the walk-through/open position shown in the current model family.

Top / seating comparison within this seat-count branch

ModelSeatsTop / PatternSource Status
230H-RDVC463DiamondCurrent public
230H-RDPC463PerforatedCurrent public
230H-RDSDC463Solid TopODS + 2024 contract

4-seat / 3-seat comparison

ModelSeatsAccessibility BranchTop / Pattern
230H-RDVC463ADA / AccessibleDiamond
230-RDVC464StandardDiamond

Seat/top color and frame color are finish options. Seat count and top/pattern type change the physical configuration, so family members are presented for comparison rather than treated as exact related-product equivalents.

46 Inch ADA Round Contour Table 3-Seat Diamond

  • Product Code: 230H-RDVC46
  • $1,747.00

Tags: 230h-rdvc46, 46 inch ada round contour table 3-seat diamond, ada accessible, diamond pattern, round, table, 46 inch
